Drum Palletizers that Pour

Description

Lift upright drum up to 20" high
Move and dispense up to 26" high
Move drum on and off pallets
Capacity: 800 Lb.
Designed to lift and pour a heavy drum at up to 26" high, when held in horizontal position. Manually rotate a drum 3600 in either direction. Raise upright drum up to 20" above the floor. Lock drum in vertical position to prevent spills while transporting, or lock in horizontal position to dispense. Also move a drum to and from pallets. Handle 55-gallon steel drum. Options for handling other drums: Top Rim Clamp for 55-gallon rimmed plastic drum (below). Bracket Assembly for fiber drum or rimless plastic drum. Diameter Adaptors for smaller diameter drum.

	Drum Movers - Drum Palletizers that Pour
Model #	Description	Power Lift		Domestic Ship Weight		Domestic Ship Dimensions
82A	Drum Palletizer with Hand Pump Hydraulic Lift, Manual Drum Tilt	-		504 Lb. (229 kg)		L50" W50" H56" (127 x 127 x 142 cm)
82A-120	Drum Palletizer with 60Hz AC Power Hydraulic Lift, Manual Drum Tilt	1PH/115V/60Hz, TEFC AC Motor		525 Lb. (239 kg)		L50" W50" H56" (127 x 127 x 142 cm)
82A-127	Drum Palletizer with 50Hz AC Power Hydraulic Lift, Manual Drum Tilt	1-Phase 50Hz Motor		525 Lb. (239 kg)		L50" W50" H56" (127 x 127 x 142 cm)
82A-124	Drum Palletizer with Air Power Lift, Manual Drum Tilt	Pneumatic Cylinder and Valve		525 Lb. (239 kg)		L50" W50" H56" (127 x 127 x 142 cm)
82A-125	Drum Palletizer with Battery Power Hydraulic Lift *, Manual Drum Tilt	12V, DC* Motor		551 Lb. (250 kg)		L50" W50" H56" (127 x 127 x 142 cm)
82A-SS	Stainless Steel Drum Palletizer with Hand Pump Hydraulic Lift, Manual Drum Tilt	-		504 Lb. (229 kg)		L50" W50" H56" (127 x 127 x 142 cm)
82A-SS-120	Stainless Steel Drum Palletizer with AC Power Hydraulic Lift, Manual Drum Tilt	1PH/115V/60Hz, TEFC AC Motor		525 Lb. (239 kg)		L50" W50" H56" (127 x 127 x 142 cm)
82A-SS-124	Stainless Steel Drum Palletizer with Air Power Lift, Manual Drum Tilt	Pneumatic Cylinder and Valve		525 Lb. (239 kg)		L50" W50" H56" (127 x 127 x 142 cm)
82A-SS-125	Stainless Steel Drum Palletizer with Battery Power Hydraulic Lift *, Manual Drum Tilt	12V, DC* Motor		551 Lb. (250 kg)		L50" W50" H56" (127 x 127 x 142 cm)
* 12V DC Power Lift includes battery, and 100/220V 50/60Hz AC charger
	Options and Accessories
Part #	Description		Domestic Ship Weight		Domestic Ship Dimensions
4560-P	Top Rim Clamp for your 55-Gallon Rimmed Plastic or Fiber Drum		11 Lb. (5 kg)		L20" W9" H17" (51 x 23 x 43 cm)
4556-P	Bracket Assembly for Rimless Plastic Drum, and recommended to more securely handle Fiber Drum		18 Lb. (8 kg)		L41" W15" H7" (104 x 38 x 18 cm)
55/30 Series	Diameter Adaptors for your smaller drums		- -		- -
4724-P	Kit to convert 82A to 82H Drum Palletizer / Mover		35 Lb. (16 kg)		L29" W19" H30" (74 x 48 x 76 cm)
Morse Green Battery Option # GB Environmentally friendly Lithium Iron Phosphate Rechargeable Battery - No harmful gas or acid leaks and spills Lighter than conventional lead-acid starting battery Up to 2000 cycles, providing up to 8 times longer cycle life than lead-acid battery No maintenance - Store up to 1 year without recharge Typical design life of 5 years Environmentally friendly battery contains no poisonous lead, no acid, and does not create gasses during charge, which regular lead-acid batteries do. Compared to lead-acid, green battery is super light, has much lower self-discharge, and does not sulfate. Rechargeable 12.8V 100Ah Battery requires no change to lead acid battery charging system.

Model Number	Description	ShipWt
82A	Drum Palletizer / Pourer, Manual Lift	504 Lb.
82A-120	Drum Palletizer / Pourer, AC Power Lift	525 Lb.
82A-124	Drum Palletizer / Pourer, Air Power Lift	495 Lb.
82A-125	Drum Palletizer / Pourer, Battery Power Lift	551 Lb.
82AM	Drum Palletizer / Pourer, Manual Lift, Spark Resistant Parts	504 Lb.
82AM-124	Drum Palletizer / Pourer, Air Power Lift, Spark Resistant Parts	495 Lb.
