Colson · Medium-heavy duty industrial
AvailableCOLSON 3 SERIES
The Colson 3 Series steps up from the 2 Series with reinforced rigs and higher load ratings up to 1,000 lbs per caster. Ideal for food service heavy carts, larger hospitality equipment, and medium-duty warehouse applications where the 2 Series tops out.
SKU Count
1,171
Capacity
250–800 lbs
Wheel ⌀
3″–6″
Mounts
4 types
Product Photography
COLSON 3 SERIES Gallery
4 photosCommon Applications
Where It's Specified
- Heavy food service carts
- Restaurant prep tables (loaded)
- Mid-size warehouse carts
- Marine equipment (heavier loads)
- Hospitality housekeeping carts
SKU catalog · live filter
Browse 1,171 SKUs
Filter by capacity, wheel diameter, tread, mount, brake. Stocked or quoted from Miami.
Showing 12of 1,171 SKUs
| Part # | Capacity | Wheel ⌀ | Tread | Mount | Brake | Bearing | Action |
|---|---|---|---|---|---|---|---|
| 3.00314.449 | 250 lbs | 3″ | Performa Rubber (Flat/Grey) | Square Stem | None | Roller | |
| 3.00614.445 COND | 300 lbs | 6″ | Performa Rubber (Condutive/Flat) | Square Stem | None | Pedestal Precision Ball | |
| 3.00308.805 TG1 | 300 lbs | 3″ | Polyolefin | Top Plate Rigid | N/A | Pedestal Precision Ball | |
| 3.00414.802 MTG7 TG1 | 375 lbs | 4″ | Polyolefin | Round Stem | None | Plain | |
| 3.00414.505 | 400 lbs | 4″ | Maxim | Square Stem | None | Pedestal Precision Ball | |
| 3.00614.109 BRK1 | 400 lbs | 6″ | Cast Iron | Square Stem | Top Lock Brake (BRK1) | Roller | |
| 3.00614.801 MTG7 TG1 | 400 lbs | 6″ | Polyolefin | Round Stem | None | Delrin | |
| 3.00514.901 MTG9 | 400 lbs | 5″ | Polyurethane HI-TECH | Round Stem | None | Delrin | |
| 3.00414.309 MTG11 BRK1 | 400 lbs | 4″ | Phenolic | Round Stem | Top Lock Brake (BRK1) | Roller | |
| 3.00317.109 | 400 lbs | 3″ | Cast Iron | Top Plate Swivel | None | Roller | |
| 3.00617.901 BRK1 | 400 lbs | 6″ | Polyurethane HI-TECH | Top Plate Swivel | Top Lock Brake (BRK1) | Delrin | |
| 3.00608.109 TG1 | 400 lbs | 6″ | Cast Iron | Top Plate Rigid | N/A | Roller |
Showing 12 featured SKUs · refine filters to load more
Need help specifying?
Caster specification is a multi-variable problem: load, floor type, tread material, mounting, environment, brake. We've solved it tens of thousands of times since 1955. Call us with your application — we'll spec the right SKU with you.
